EZ Grout Manufacturing Pumps

EZG started as EZ Grout and was born from the desire of one man to improve the quality of equipment used in masonry. In 1988 founder and CEO Damian Lang sought to help contractors increase efficiency and profitability with American made products built from hands-on experience. Masonry equipment available at the time lacked sturdiness and reliability, causing operators to experience systemic machine clogs and mechanical failures.


Damian developed the first Grout Hog® after numerous prototypes. Over time, he perfected models by patenting new features specific only to the EZ Grout line, like clog-prevention mechanisms and an innovative delivery system.

Once Damian's invention proved useful, he turned his creative focus to other areas of construction and masonry, eventually releasing Mud Hog®, Uphill Grout Hog®, Hog Slopper®, Hog Leg®, Hog Trough® and Booger Hog®. In the early 2000's Damian introduced his Fence Hog® which now includes several models for the fencing industry. This automated fence installation equipment is well-known for saving construction crews hundreds of hours on large projects on virtually any terrain


For more information and a complete description of the pumps we offer by EZ GROUT, please click on the category links below.


Hog Pump

• HP-20T4 - Grout, Mortar and Concrete Pump


"EZG" Mixer Series

• EZG7 - Grout, Mortar and Concrete Mixer

• EZG9 - Grout, Mortar and Concrete  Mixer

• EZG12 - Grout, Mortar and Concrete  Mixer


"Mud Hog" Mixer Series

• Mud Hog Mixer MH9 - Grout, Mortar and Concrete Mixer

• Mud Hog Mixer MH20 - Grout, Mortar and Concrete Mixer


"Grout Hog" Pump Series

• Grout Hog Pump GH75

• Grout Hog Pump GPH75

• Grout Hog Pump UGH75

• Grout Hog Pump UGPH75




Hog Pumps

EZG Manufacturing Hog Pump HP-20T4

Hog Pump HP-20T4

The triple use Hog Pump handles most types of construction material and is designed specifically for grout, mortar and concrete. The front can be hitched onto a truck trailer to easily bring to job sites.


The pump's valve uses a reversible S-Tube which is safer and easier to use than traditional ball valve designs. The HP-20T4 is ideal for large pump jobs requiring grout, mortar or even pea stones.


KEY FEATURES

• Triple Use: Grout, Mortar and Concrete

• Ideal for filling block walls with grout or pea-rock

• Delivers up to 20 yd3 per hour

• Features an 8 cu.ft. hopper

• Handles up to 3/4” aggregate

• Fully reversible S-Tube valve for increased ease and safety over “ball valve” designs


Weight Dry:......................................... 3500 lbs

Length:................................................ 7'

Width:.................................................. 3'

Hopper Height:................................... 4'

Brakes:................................................. Electric

Tires:....................................................

Axle:..................................................... Single

Hopper Capacity:................................ 8 cu ft

Fuel Tank Capacity:............................ 20 gal

Engine:................................................ Kutota DOC FInal Tier 4 58hp Diesel

Hydraulic Tank Capacity:...................

Main Hydraulic Pump:.......................

Material Valve:.................................... S-Tube

Discharge Diameter Outlet:............... 4"

Concrete Cylinder Stroke:................. 30"

Concrete Cylinder Diameter:............ 4"

Maximum Aggregate:........................ 3/4"

Piston Head Pressure:...................... 650 psi

Theoretical Output (C.Y.P.H.):........... 20

"EZG" Mixer Series

EZG Manufacturing Mixer EZG7

EZG Mixer EZG7

The EZG® Mixer homogeneously mixes all heavy aggregates on the job site giving you as much time as you need—for any project—before the precast hardens. Our mixers make setting the final product a seamless process. The mixers come in three different sizes to handle low to high volumes.


The manual dump mixers are triple use for grout, mortar and concrete. They feature our #80 chain-driven system and are designed with bearings spaced from the seals to improve bearing durability.




Weight Dry:........................................ 850 lbs

Length:............................................... 73” (107” with Tongue)

Width:................................................. 47”

Height:............................................... 58” (67” with dump handle)

Load Height:...................................... 48”

Tires:...................................................

Axle:................................................... Single

Hitch:................................................. 2” Ball

Hopper Capacity:.............................. 1.5 to 2 bag or 7 cu.ft.

Engine:.............................................. 7.9 HP Honda Gas

Maximum Aggregate:....................... 75”

Discharge:......................................... Up to 21” high

Drum Thicknesss:............................. 3/16”

Structural Tubing:............................ 4” x 6” rectangular

Shaft:................................................ 1.25” Solid Steel

EZG Manufacturing Mixer EZG9

EZG Mixer EZG9

The EZG® Mixer homogeneously mixes all heavy aggregates on the job site giving you as much time as you need—for any project—before the precast hardens. Our mixers make setting the final product a seamless process. The mixers come in three different sizes to handle low to high volumes.


The manual dump mixers are triple use for grout, mortar and concrete. They feature our #80 chain-driven system and are designed with bearings spaced from the seals to improve bearing durability.


Weight Dry:........................................ 970 lbs

Length:............................................... 76” (110” with Tongue)

Width:................................................. 47”

Height:............................................... 67” (77” with dump handle)

Load Height:...................................... 56”

Tires:...................................................

Axle:................................................... Single

Hitch:................................................. 2” Ball

Hopper Capacity:.............................. 3 to 4 bag or 12 cu.ft.

Engine:.............................................. 11.7 HP Honda Gas

Maximum Aggregate:....................... 75”

Discharge:......................................... Up to 20” high

Drum Thicknesss:............................. 1/4”

Structural Tubing:............................ 4” x 7” rectangular

Shaft:................................................ 1.75” Solid Steel

EZG Manufacturing Mixer EZG12

EZG Mixer EZG12

The EZG® Mixer homogeneously mixes all heavy aggregates on the job site giving you as much time as you need—for any project—before the precast hardens. Our mixers make setting the final product a seamless process. The mixers come in three different sizes to handle low to high volumes.


The manual dump mixers are triple use for grout, mortar and concrete. They feature our #80 chain-driven system and are designed with bearings spaced from the seals to improve bearing durability.


Weight Dry:........................................ 1231 lbs

Length:............................................... 76” (110” with Tongue)

Width:................................................. 47”

Height:............................................... 67” (77” with dump handle)

Load Height:...................................... 48”

Tires:...................................................

Axle:................................................... Single

Hitch:................................................. 2” Ball

Hopper Capacity:.............................. 1.5 to 2 bag or 7 cu.ft.

Engine:.............................................. 7.9 HP Honda Gas

Maximum Aggregate:....................... 75”

Discharge:......................................... Up to 21” high

Drum Thicknesss:............................. 3/16”

Structural Tubing:............................ 4” x 6” rectangular

Shaft:................................................ 1.25” Solid Steel

"Mud Hog" Mixer Series

EZG Manufacturing Mud Hog Mixer MH9

Mud Hog Mixer MH9

A solid grate cover can be added to any Mud Hog mixer to help control dust on the job site. The cover has two separate openings - one for adding mix and the other for water intake. With OSHA’s new silica diet regulation, this cover can make a big impact on your ability to comply!


KEY FEATURES

• Triple use: Grout, Concrete and Mortar

• Becomes a portable batch plant for mixing grout on site - compacts to fit into standard 8' truck bed

• Ideal for use with silo mix or bag mixes

• Hydraulic dump and drive

• Reversible mixing paddles prevent clogging

• Vertical paddle orientation to minimize splashing and cut through material

• Loads below waist level and dumps high with adjustable heights to optimize ergonomic operation

• Fork pockets accessible from all sides

• Adjustable legs and outriggers for stability

• Dumps into the Grout Hog® for easy masonry block filling

• Manual recoil and electric start




Weight Dry:........................................ 1435 lbs

Length:............................................... 92"

Width:................................................. 41.5"

Height:................................................ 49"

Load Height:.......................................

Tires:...................................................

Axle:....................................................

Hitch:..................................................

Hopper Capacity:............................... 2 to 3 bag or 9 cu.ft.

Hopper Capacity:............................... 2 to 3 bag or 9 cu.ft.Gas

Maximum Aggregate:......................... 3/4”

Discharge:.......................................... Up to 26” high

Drum Thicknesss:.............................. 1/4”

Structural Tubing:.............................

Shaft:.................................................

Fuel Tank Capacity:..........................

Dump System:................................... Hydraulic

Drive System:.................................... Hydraulic


Options

• 5 HP Electric Motor - 1PH/230V

• 5 HP Electric Motor - 3PH/230V

• 5 HP Electric Motor - 3PH/460V

• Towing light kit for road safety

• Solid grating available to minimize dust

• Add fork pockets for versatility

• Water bar for easy filling - optional, re-settable meter

EZG Manufacturing Mud Hog Mixer MH20

Mud Hog Mixer MH20

A solid grate cover can be added to any Mud Hog mixer to help control dust on the job site. The cover has two separate openings - one for adding mix and the other for water intake. With OSHA’s new silica diet regulation, this cover can make a big impact on your ability to comply!


KEY FEATURES

• Triple use: Grout, Concrete and Mortar

• Becomes a portable batch plant for mixing grout on site - compacts to fit into standard 8' truck bed

• Ideal for use with silo mix or bag mixes

• Hydraulic dump and drive

• Reversible mixing paddles prevent clogging

• Vertical paddle orientation to minimize splashing and cut through material

• Loads below waist level and dumps high with adjustable heights to optimize ergonomic operation

• Fork pockets accessible from all sides

• Adjustable legs and outriggers for stability

• Dumps into the Grout Hog® for easy masonry block filling

• Manual recoil and electric start


Weight Dry:........................................ 2295 lbs

Length:............................................... 96"

Width:................................................. 44"

Height:................................................ 53"

Load Height:.......................................

Hopper Capacity:............................... 6 to 7 bag or 20 cu.ft.

Engine:............................................... 11.7 HP Honda Gas

Maximum Aggregate:......................... 3/4” (1.9 cm)

Discharge:.......................................... Up to 26” high

Drum Thicknesss:.............................. 3/8" Drum End, 5/16" Drum Wrap Thickness

Structural Tubing:.............................

Shaft:.................................................

Fuel Tank Capacity:..........................

Dump System:................................... Hydraulic

Drive System:.................................... Hydraulic


Options

• 10 HP Electric Motor - 1PH/230V

• 10 HP Electric Motor - 3PH/230V

• 10 HP Electric Motor - 3PH/460V

• 9.5 HP Kubota Diesel Engine

• Solid grating available to minimize dust

• Water bar for easy filling - optional, re-settable meter

"Grout Hog" Pump Series

EZG Manufacturing Grout Hog Pump GH75

Grout Hog Pump GH75

After more than a decade of development and thousands of field tests the Grout Hog® has been streamlined for convenience and efficiency.


CONVENIENCE

Each model includes a unique swiveling base that reduces the number of moves required by the forklift. These grout delivery systems can be operated via wireless remotes, allowing operators greater pour precision.


EFFICIENCY

Both horizontal and uphill models require only two people for safe operation and complete masonry block fill, one to guide the hose and the other to drive the forklift. The delivery system means no more carrying large buckets of grout to the site.

Instead, your workers can pour in a 17' radius and easily manipulate the direction without moving the forklift. Cleanup is fast and easy with the removable auger which reduces cleanup to less than 15 minutes.


KEY FEATURES

• Two Laborers

• Three minute set up

• 15 minute clean up

• Weight on forklift instead of men

• CAN grout a green joint without harm


Weight Dry:......................................... 985 lbs

Length:................................................ 92"

Width:.................................................. 41.5"

Height:................................................. 49"

Hopper Height:................................... "

Hopper Capacity:................................ 3/4 yd3 (.57 m3)

Fuel Tank Capacity:............................

Engine:................................................ Auxiliary Hydraulic Power

Hydraulic Tank Capacity:...................

Main Hydraulic Pump:.......................

Material Valve:....................................

Discharge Diameter Outlet:............... "

Concrete Cylinder Stroke:................. "

Concrete Cylinder Diameter:............ "

Maximum Aggregate:........................ 3/4"

Piston Head Pressure:...................... psi

Theoretical Output (C.Y.P.H.):...........


Options

• Power Source

• Crane bail for higher reach and better access - GPHC75 (adds 2' of height and 90 lbs. of weight)

• Wireless Remote

EZG Manufacturing Grout Hog Pump GPH75

Grout Hog Pump GPH75

After more than a decade of development and thousands of field tests the Grout Hog® has been streamlined for convenience and efficiency.


CONVENIENCE

Each model includes a unique swiveling base that reduces the number of moves required by the forklift. These grout delivery systems can be operated via wireless remotes, allowing operators greater pour precision.


EFFICIENCY

Both horizontal and uphill models require only two people for safe operation and complete masonry block fill, one to guide the hose and the other to drive the forklift. The delivery system means no more carrying large buckets of grout to the site.

Instead, your workers can pour in a 17' radius and easily manipulate the direction without moving the forklift. Cleanup is fast and easy with the removable auger which reduces cleanup to less than 15 minutes.


KEY FEATURES

• Two Laborers

• Three minute set up

• 15 minute clean up

• Weight on forklift instead of men

• CAN grout a green join without harm


Weight Dry:......................................... 1435 lbs

Length:................................................ 92"

Width:.................................................. 41.5"

Height:................................................. 49"

Hopper Height:................................... "

Hopper Capacity:................................ 3/4 yd3 (.57 m3)

Fuel Tank Capacity:............................

Engine:................................................ 11.7 HP Honda Gas

Hydraulic Tank Capacity:...................

Main Hydraulic Pump:.......................

Material Valve:....................................

Discharge Diameter Outlet:............... "

Concrete Cylinder Stroke:................. "

Concrete Cylinder Diameter:............ "

Maximum Aggregate:........................ 3/4"

Piston Head Pressure:...................... psi

Theoretical Output (C.Y.P.H.):...........


Options

• Power Source

• Crane bail for higher reach and better access - GPHC75 (adds 2' of height and 90 lbs. of weight)

• Wireless Remote

EZG Manufacturing Grout Hog Pump UGH75

Grout Hog Pump UGH75

After more than a decade of development and thousands of field tests the Grout Hog® has been streamlined for convenience and efficiency.


CONVENIENCE

Each model includes a unique swiveling base that reduces the number of moves required by the forklift. These grout delivery systems can be operated via wireless remotes, allowing operators greater pour precision.


EFFICIENCY

Both horizontal and uphill models require only two people for safe operation and complete masonry block fill, one to guide the hose and the other to drive the forklift. The delivery system means no more carrying large buckets of grout to the site.

Instead, your workers can pour in a 17' radius and easily manipulate the direction without moving the forklift. Cleanup is fast and easy with the removable auger which reduces cleanup to less than 15 minutes.


KEY FEATURES

• Two Laborers

• Three minute set up

• 15 minute clean up

• Weight on forklift instead of men

• CAN grout a green join without harm


Weight Dry:......................................... 1055 lbs

Length:................................................ 100"

Width:.................................................. 37"

Height:................................................. 50.5"

Hopper Height:................................... "

Hopper Capacity:................................ 3/4 yd3 (.57 m3)

Fuel Tank Capacity:............................

Engine:................................................ Auxiliary Hydraulic Power

Hydraulic Tank Capacity:...................

Main Hydraulic Pump:.......................

Material Valve:....................................

Discharge Diameter Outlet:............... "

Concrete Cylinder Stroke:................. "

Concrete Cylinder Diameter:............ "

Maximum Aggregate:........................ 1/2"

Piston Head Pressure:...................... psi

Theoretical Output (C.Y.P.H.):...........


Options

• Power Source

• Crane bail for higher reach and better access  - UGPHC75 (adds 90 lbs. of weight)

• Wireless Remote

EZG Manufacturing Grout Hog Pump UGPH75

Grout Hog Pump UGPH75

After more than a decade of development and thousands of field tests the Grout Hog® has been streamlined for convenience and efficiency.


CONVENIENCE

Each model includes a unique swiveling base that reduces the number of moves required by the forklift. These grout delivery systems can be operated via wireless remotes, allowing operators greater pour precision.


EFFICIENCY

Both horizontal and uphill models require only two people for safe operation and complete masonry block fill, one to guide the hose and the other to drive the forklift. The delivery system means no more carrying large buckets of grout to the site.


Instead, your workers can pour in a 17' radius and easily manipulate the direction without moving the forklift. Cleanup is fast and easy with the removable auger which reduces cleanup to less than 15 minutes.


KEY FEATURES

• Two Laborers

• Three minute set up

• 15 minute clean up

• Weight on forklift instead of men

• CAN grout a green join without harm


Weight Dry:......................................... 1475 lbs

Length:................................................ 100"

Width:.................................................. 37"

Height:................................................. 50.5"

Hopper Height:................................... "

Hopper Capacity:................................ 3/4 yd3 (.57 m3)

Fuel Tank Capacity:............................

Engine:................................................ 11.7 HP Honda Gas

Hydraulic Tank Capacity:...................

Main Hydraulic Pump:.......................

Material Valve:....................................

Discharge Diameter Outlet:............... "

Concrete Cylinder Stroke:................. "

Concrete Cylinder Diameter:............ "

Maximum Aggregate:........................ 1/2"

Piston Head Pressure:...................... psi

Theoretical Output (C.Y.P.H.):...........


Options

• Power Source

• Crane bail for higher reach and better access  - UGPHC75 (adds 90 lbs. of weight)

• Wireless Remote
