Putzmeister Pumps

Putzmeister manufactures boom truck pumps, trailer and line pumps, city pumps and placing - placement booms for all types of concrete pumping and specialty applications. Their trailer-mounted and stationary line pumps include rock valve and ball valve models.


Putzmeister trailer pumps and line pumps are offered in small and very large S-Valve models. The smaller models are suitable for pumping mortar, grout, shotcrete, plaster and fireproofing mixes. The larger models handle the heaviest concrete pumping tasks required by concrete high-rise construction, long-distance conveying and tunnel construction.


Putzmeister pumps are known for their innovative features, durability and high performance. Putzmeister is a world leader in the manufacture of concrete pumps.


For more information and a complete description of the pumps we offer by PUTZMEISTER, please click on the links below.


TK 50 Tier 3 - Concrete/Shotcrete Pump

TK 50 Tier 4F - Concrete/Shotcrete Pump

TK 40 Tier 41 - Concrete/Shotcrete Pump

P13 DMR - Mortar Machine

TK 70 Tier 4F - Variety Of Materials Pump

TK 7 Tier - Wet-Process Refractory Applications

PUTZMEISTER TK 50 TIER 3

PUTZMEISTER TK 50 TIER 3

The Putzmeister Thom-Katt TK 50 Trailer-Mounted Concrete/Shotcrete Pump gives more horse power for shotcrete work, and is ideal for a wide variety of concrete placing jobs and for pumping structural concrete. It features an angled hopper that’ s easier to fill and clean. The TK 50 can pump a variety of materials at up to 54 yd³/hr (41m³/hr) handle the harshest mixes, and tackle a variety of civil application, concrete placing jobs and for pumping structural concrete.


KEY FEATURES

  • Reversible pump for safety

  • Reliable S-Valve

  • 38 gal (144L) hydraulic tank

  • 74.5" (1.89m) wide, high strength trailer for maximum towing stability

  • Angled hopper


Weight:.................................................. 4629.708 lbs (2,100kg)

Height:................................................... 7'6" (2.28m)

Width:.................................................... 6' 2.5" (1.89m)

Length:.................................................. 15' 11" (4.85m)

Engine Model:....................................... Deutz TCD2012L04m

Horsepower:......................................... 96.5536 hp (72kW

Fuel Tank Capacity:.............................. 26 gal (98L)

Maximum Volume Output:.................. 54 yd³/hr (41m³/hr)*

Maximum Concrete Pressure:............. 1145.8 psi (79 bar)

Hydraulic Tank Capacity:.................... 46 gal (175L)

Maximum Aggregate Size:................... 1.50" (38mm)

Material Cylinders:............................... 6" x 39" (150 x 1,000mm)

Maximum Strokes Per minute:........... 43

S-Valve (cast):...................................... 6" x 5" (150 x 125mm)

Number Of Shift Cylinders:................. A

Hopper Height:.................................... 4’ 1” (1,245mm)

Hopper Capacity:................................ 9.53496 ft³ (270L)

Outlet Diameter:................................. 5” (125mm)

Trailer:................................................. Single Axel, Electric Brakes


MORE HORSEPOWER FOR SHOTCRETE WORK

IDEAL FOR A WIDE VARIETY OF CONCRETE PLACING

*Optional electric versions have decreased output. All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.

PUTZMEISTER TK 50 TIER 4F

PUTZMEISTER TK 50 TIER 4F

The Putzmeister Thom-Katt TK 50 Trailer-Mounted Concrete/Shotcrete Pump gives more horsepower for shotcrete work, and is ideal for a wide variety of concrete placing jobs and for pumping structural concrete. It features an angled hopper that’s easier to fill and clean. The TK 50 can pump a variety of materials at up to 54 yd³/hr, handle the harshest mixes, and tackle a variety of civil applications.


KEY FEATURES

  • Reversible pump for safety

  • Reliable S-Valve

  • 38 gal (144L) hydraulic tank

  • 74.5" (1.89m) wide, high strength trailer for maximum towing stability

  • Angled hopper


Weight:.................................................. 6,200 lbs (2,100kg)

Height:................................................... 7'6" (2.28m)

Width:.................................................... 6' 2.5" (1.89m)

Length:.................................................. 15' 11" (4.85m)

Engine Model:....................................... Cummins QSF3.8

Horsepower:......................................... 100 hp (75kW)

Fuel Tank Capacity:.............................. 28 gal (105L)

Maximum Volume Output:.................. 54 yd³/hr (41m³/hr)*

Maximum Concrete Pressure:............. 1,150 psi (79 bar)

Hydraulic Tank Capacity:.................... 46 gal (175L)

Maximum Aggregate Size:................... 1.50" (38mm)

Material Cylinders:............................... 6" x 39" (150 x 1,000mm)

Maximum Strokes Per minute:........... 43

S-Valve (cast):...................................... 6" x 5" (150 x 125mm)

Number Of Shift Cylinders:................. A

Hopper Height:.................................... 49" (1,245mm)

Hopper Capacity:................................ 9.5 ft³ (270L)

Outlet Diameter:................................. 5 HD (125mm)

Trailer:................................................. Single Axel, Electric Brakes


MORE HORSEPOWER FOR SHOTCRETE WORK, IDEAL FOR A WIDE VARIETY OF CONCRETE PLACING.

*Optional electric versions have decreased output. All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.

PUTZMEISTER TK 40 TIER 41

PUTZMEISTER TK 40 TIER 41

The TK 40 Trailer-Mounted Concrete/Shotcrete Pump is a rugged workhorse that can handle aggregate up to 1-1/2 inch minus at up to 40 yd³/hr. Ideal for shotcrete work, this pump also works well in a wide variety of concrete placing jobs and for pumping structural concrete.


KEY FEATURES

  • Reversible pump for safey

  • Reliable S-Valve

  • 38 gallon hydraulic tank

  • 74.5 inch wide, high strength trailer for maximum towing stability


Weight:.................................................. 4629.708 lbs (2,100kg)

Height:................................................... 7'3" (2.21m)

Width:.................................................... 6'2" (1.88m)

Length:.................................................. 191" (4.85m)

Engine Model:....................................... Deutz TD2011L04i

Horsepower:......................................... 68 hp (51kW)

Fuel Tank Capacity:.............................. 26 gal (98L)

Maximum Volume Output:.................. 40 yd³/hr (30m³/hr)*

Maximum Concrete Pressure:............. 1,150 psi (79 bar)

Hydraulic Tank Capacity:.................... gal (L)

Maximum Aggregate Size:................... 1.50" (38mm)

Material Cylinders:............................... 6" x 39"  (150 x 1,000mm)

Maximum Strokes Per minute:........... 31

S-Valve (cast):...................................... 6" x 5" (150 x 125mm)

Number Of Shift Cylinders:................. A

Hopper Height:.................................... 49" (1,245mm)

Hopper Capacity:................................ 9.5 ft³ (270L)

Outlet Diameter:................................. 5 HD (125mm)

Trailer:................................................. Single Axel, Electric Brakes


BIG BOOM EXPERTISE IN A SMALLER MACHINE.

*Optional electric versions have decreased output. All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.

PUTZMEISTER P 13 DMR

PUTZMEISTER P 13 DMR

With the Putzmeister P 13, you can mix, pump and spray using just one robust and powerful mortar machine. This machine works with pre-mixed and site-mixed mortar up to 0.4-inch (10mm) grain size, with three speed settings offering an adjustable output. The P 13 is ideal for use with lime mortar, cement mortar, lime-cement mortar, scratch coats, liquid screed with or without aggregate, bedding mortar, filling mortar, masonry mortar, and bentonite slurry.


KEY FEATURES

  • Positive mixer ensures optimum mix quality

  • Large opening at the bottom of the drum allows mix to fall directly in the hopper

  • Uninterrupted pumping with a large capacity mixer and hopper

  • KA 230 piston pump for a maximum output of 2.83 cubic feet per minute (80 liter per minute)


SPECIAL FEATURES

  • Robust components for reduced wear and tear.

  • Mechanically driven vibrating screen to sort oversized grains out of the mortar mix

Weight:......................................................  lbs (kg)

Height:....................................................... 37" (1,450mm)

Width:........................................................ 65" (1,640mm)

Length:...................................................... 118" (3,000mm)

Breaks:......................................................

Tires:.........................................................

Axle:.......................................................... Single

Engine:..................................................... 2-Cylinder Diesel

Horsepower:............................................ 16.76278 hp (12.5 kw) at 2,800 rpm

AIr Compressor:....................................... 2-Cylinder

PSI:........................................................... 51 PSI (3.5 bar) 10.59 ft³/min(300L/min)

Fuel Tank Capacity:................................  gal (L)

Maximum Volume Output:..................... 74 yd³/hr (57m³/hr)*

Maximum Concrete Pressure:................ 1,130 psi (78 bar)

Horizontal Pumping Distance*:............. Up to 984' 3" (300m)

Vertical Pumping Distance*:.................. Up to 328' 1" (100m)

Pump Type:............................................ Mechanical Piston Pump KA 230

Delivery Pressure:.................................. 580 psi (40bar)

Theoretical Delivery Rate*:.................... 0.71 - 2.83 ft³/min (20-80L/min) (150 x 125mm)

Material Cylinder Diameter:.................. 4" (100mm)

Material Cylinder Stroke:....................... 5" (130mm)

Maximum Aggregate Size:..................... 0.40" (10mm)


MIX, PUMP AND SPRAY WITH ONE ROBUST AND POWERFUL MORTAR MACHINE.

*All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.

PUTZMEISTER TK 70 TIER 4F

PUTZMEISTER TK 70 TIER 4F

Ideal for structural concrete jobs, the Putzmeister Thom-Katt TK 70 trailer-mounted pump can handle a variety of materials, including the harshest mixes. With a maximum volume output of up to 74 yd³/hr (57m³/hr), the TK 70 can tackle a variety of civil applications.


KEY FEATURES

• Reliable S-Valve

• 38 gal (144L) hydraulic tank

• 74.5" (1.89m) wide, high strength trailer for maximum towing stability


Weight:.................................................. 7,000 lbs (3,175kg)

Height:................................................... 87" (2.21m)

Width:.................................................... 74.50" (1.89m)

Length:.................................................. 191" (4.85m)

Engine Model:....................................... Cummins QSF3.8

Horsepower:......................................... 100 hp (75kW)

Fuel Tank Capacity:.............................. 28 gal (105L)

Maximum Volume Output:.................. 74 yd³/hr (57m³/hr)*

Maximum Concrete Pressure:............. 1,130 psi (78 bar)

Hydraulic Tank Capacity:.................... 44 gal (167L)

Maximum Aggregate Size:................... 1.50" (38mm)

Material Cylinders:............................... 7" x 39"  (180 x 1,000mm)

Maximum Strokes Per minute:........... 44

S-Valve (cast):...................................... 6" x 5" (150 x 125mm)

Number Of Shift Cylinders:................. 2

Hopper Height:.................................... 49" (1,245mm)

Hopper Capacity:................................ 9.5 ft³ (270L)

Outlet Diameter:................................. 5 HD (125mm)

Trailer:................................................. Single Axel, Electric Brakes


CAN PUMP A VARIETY OF MATERIALS, INCLUDING THE HARSHEST MIXES.

*Optional electric versions have decreased output. All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.

PUTZMEISTER TK 7 PUMP

PUTZMEISTER TK 7 PUMP

The Putzmeister's TK 7 is ideal for wet-process refractory applications. Its high performance, up to 7 yd³/hr, is coupled with the low operating costs of S-Valve pumps. Critical for safety, the pump is reversible at any point in the stroke, a feature not offered by mechanical pumps.


KEY FEATURES

• Reversible pump for safetyReliable S-Valve

• 38 gal (144L) hydraulic tank

• 74.5” (1.89m) wide, high strength trailer for maximum towing stability

• Hydraulically operated 13 ft³ (368L) detachable mixer for large amounts of material (optional)


Weight:.................................................. 2,360 lb (1,070kg)

Height:................................................... 54" (1.37m)

Width:.................................................... 37.2" (0.94m)

Length:.................................................. 87.4" (2.22m)

Engine Model:....................................... TEFC Motor

Horsepower:......................................... 30 hp (22kW)

Process Type:........................................ Wet

Fuel Tank Capacity:.............................. 15 gal

Maximum Volume Output:.................. 7 yd³/hr (4.6m³/hr)*

Maximum Concrete Pressure:............. 1,240 psi (85 bar)

Hydraulic Tank Capacity:..................... 28 gal (105L)

Maximum Aggregate Size:................... 0.75" (19mm)

Material Cylinders:............................... 2" x 24" (51x610mm)

Maximum Strokes Per minute:............ 56

S-Valve (cast):....................................... 3" x 3"  (76x76mm)

Hopper Height:.................................... 42.1" (1,070mm)

Hopper Capacity:................................. 7.8 ft³ (220L)

Outlet Diameter:.................................. 36


IDEAL FOR WET-PROCESS REFRACTORY APPLICATIONS

*Optional electric versions have decreased output. All data provided is based on experience and depends on the material used. Specifications subject to change without prior notice, no responsibility is taken for the correctness of this information. Other data can be obtained on request.
