Priddy Pumps

Priddy is commitment to providing the highest quality concrete pumping equipment in the industry with over 35+ years’ experience. Success comes from our experience to improve and revolutionize our industry by eliminating pipeline surge as opposed to just a bandaid. Solution. We are committed to keeping it a simple 2 cylinder "YS-Tube" concrete pump with dependability & Quality a Top Priority!


Priddy Pumps

Priddy CFA70-7-48-6

Priddy CFA70-7-48-6

PRIDDY "Continuous Flow" Concrete Pumps eliminate surge by utilizing a patented 3-position “YS-Tube” & Trapezoid cutting ring.  Pressure and flow of the concrete material is never lost during the valve shift.  This also allows the pumping pistons to both discharge simultaneously at the beginning and ending of their strokes!


KEY FEATURES

• Cylinders made of reinforced chromium plated material


SPECIAL FEATURES

• Remote control operation


Weight Dry:......................................... 8400 lbs

Length:................................................ 192"

Width:.................................................. 72"

Hopper Height:................................... 46"

Brakes:................................................. Electric

Tires:.................................................... 235/80 R16

Axle:..................................................... Flexride 5500 lbs

Hopper Capacity:................................ 9 cu ft

Fuel Tank Capacity:............................ 25 gal

Engine:................................................ Cat 4.4 729 hp

Hydraulic Tank Capacity:................... 65 gal

Main Hydraulic Pump:....................... Rexroth ALLV060

Material Valve:.................................... YS-Tube

Discharge Diameter Outlet:............... 6"

Concrete Cylinder Stroke:................. 48"

Concrete Cylinder Diameter:............ 7"

Maximum Aggregate:........................ 1 1/2"

Piston Head Pressure:...................... 800 psi

Theoretical Output (C.Y.P.H.):........... 70
