WESTERN EQUIPMENT MANUFACTURING PUMPS

Western is renowned for building production equipment for the plaster, stucco and fireproofing processes used in production of residential and commercial construction. Western builds the best equipment because we get involved and listen to the people in the field in order to integrate the features that make them more competitive and profitable.

It is not uncommon for Western to custom build enhancements to our equipment at the direction of our customers. The tandem axle trailer seen on our Predator pumps, on-board water batching system for fireproofing, our Powerdump feature (hydraulic powered mixer coupled with hydraulic batch dumping) and the wide selection of diesel power options are all examples of this. Continuous product improvement and prototype testing is why we are always a step ahead of the competition.


Our 90,000 square foot facility includes high quality manufacturing equipment where we produce the majority of the components here on the premises. This gives us the ability to control costs and to control the durability of the component. Additionally, designing and manufacturing our own components gives us the ability to rapidly evolve features and future models so that our customer can realize better productivity and reliability.


For more information and a complete description of the pumps we offer by WESTERN EQUIPMENT MANUFACTURING, please click on the category links below.


Predator Pumps

Predator Series Single Axel Mobile Pump


GROUT & CONCRETE PUMPS

• W30SD --Grout & Concrete Pump


Plaster Mixers

• 1200 Plaster Mixer - Mechanical Drive

• 1200 Plaster Mixer - Hydraulic Drive


Predator Pumps

Western Equipment Manufacturing Predator Series Single Axel Mobile Pump

Predator Series Single Axel Mobile Pump

This is the most complete piston pump available and it comes equipped with all of the features that bring productivity to the highest level. Choose from mechanical and hydraulic drives to features made especially for the fireproofing contractor that requires the best.


KEY FEATURES

• Your choice of 1200 Western Mixer

• Heavy duty wishbone trailer with 16" wheels. The safest pump on the road

• 5,000 Lb. jack and stabilizers for a safe and faster set-up

• Water delivery system speeds mixing time by delivering 10 gallons of water in about 6 seconds across the length of the mixer rail.


This is the most complete dual engine piston pump available and it comes equipped with all the features that bring productivity to the highest level.


Weight Dry:.................................... 4420 lbs Diesel

 Weight Dry:................................... 4080 lbs Gas

Length:.......................................... 171”

Width:............................................ 84”

Height:.......................................... 75” with Handel

Material Charging Height:............ 58”

Water Tank:...................................

Material Outlet:............................ 2” NPT (standard), 3” NPT

Axle:.............................................. Tandem

Hopper Capacity:......................... 12 cu ft

Fuel Tank Capacity:...................... 6.25 gal

Compressor:................................. Quincy PLS 2 Cylinder 14 CFM

Pumping Cylinder:....................... 3.75”, 3.5” (standard), 2.75”

Maximum Pressure:..................... 1000 PSI

Output Rate:................................. 9.6 yd3/hr

Maximum Aggregate:................... 1/8” minus

Pump Power:................................ Hatz 2M41 (37 HP) Diesel

Pump Power:................................ Wisconsin VH4D (30 HP) Gas

Pump:........................................... Reciprocating Piston

Western Equipment Manufacturing Predator Series Tandem Axel Mobile Pump

Predator Series Tandem Axel Mobile Pump

The best quality pump now available with brakes and suspension. The picture featured is of our Predator V600 Pump, which comes equipped with the powerdump feature.


KEY FEATURES

• Manifold - High volume cast steel manifold assembly with 2 or 3 inch outlet

• Heavy Duty Fenders - Specifically designed with the contractor in mind and fabricated out of 10 Gauge steel for enhanced durability

• Fender Line - Custom fitted heavy duty liners protect brake drums and wheels from materials being pumped

• Tandem Axle - Two 8,000 lbs rated axles with torsion suspension provides you with a safer and smooth ride

• ”A" Frame - The mandrel bent "A" frame design makes this trailer exceptionally strong

• Mixer and Pump Option - The tandem trailer is available for all Mobile PREDATOR Pump/Mixer configurations


Weight Dry:................................... 5200 lbs

Length:.......................................... 204”

Width:............................................ 86”

Height:.......................................... 75” with Handel

Material Charging Height:............ 50”, 58”, 50” (powerdump)

Water Tank:................................... 35 gal

Material Outlet:............................. 2” NPT (standard), 3” NPT

Axle:............................................... Tandem

Hopper Capacity:.......................... 12 cu ft

Fuel Tank Capacity:....................... 6.25 gal

Compressor:.................................. Quincy PLS 2 Cylinder 14 CFM

Pumping Cylinder:......................... 3.75”, 3.5” (standard), 2.75”

Maximum Pressure:....................... 1000 PSI

Output Rate:................................... 9.6 yd3/hr

Maximum Aggregate:..................... 1/8” minus

Pump Power:.................................. Wisconsin VH4D (30 HP) Gas

Pump Power:.................................. Hatz 2M41 (37 HP) Diesel

Pump:............................................. Reciprocating Piston

Western Equipment Manufacturing Predator Series Tag Pump

Predator Series Tag Pump

This versatile Tag-Pump configuration of the Predator comes with a removable tow bar and a torsion bar suspension for easy and smooth towing.


Weight Dry:................................... 2350 lbs

Length:.......................................... 98” (add 42” for low bar)

Width:............................................ 56"

Height:........................................... 52"

Material Charging Height:............ 58”

Water Tank:..................................

Material Outlet:............................. 2” NPT (standard), 3” NPT

Axle:............................................... Single

Hopper Capacity:.......................... 12 cu ft

Fuel Tank Capacity:....................... 6.25 gal

Compressor:.................................. Quincy PLS 2 Cylinder 14 CFM

Pumping Cylinder:......................... 3.75”, 3.5” (standard), 2.75”

Maximum Pressure:....................... 1000 PSI

Output Rate:................................... 9.6 yd3/hr

Maximum Aggregate:..................... 1/8” minus

Pump Power:.................................. Wisconsin VH4D (30 HP) Gas

Pump Power:.................................. Hatz 2M41 (37 HP) Diesel

Pump:............................................. Reciprocating Piston

Western Equipment Predator Series Skid Pump

Predator Series Skid Pump

This Skid Pump set up is easily mounted on truck beds, trailers, or even roll-on carts in order to reach the toughest places while maintaining the high pumping output. **Custom designs are available


Weight Dry:............................... 2100 lbs

Length:......................................... 98”

Width:........................................... 56”

Height:.......................................... 47”

Hopper Height:......................... 25.75”

Material Charging Height:........... 58”

Water Tank:..................................

Material Outlet:........................... 2” NPT (standard), 3” NPT

Axle:............................................. Skid

Hopper Capacity:........................ 12 cu ft

Fuel Tank Capacity:..................... 6.25 gal

Compressor:................................ Quincy PLS 2 Cylinder 14 CFM

Pumping Cylinder:....................... 3.75”, 3.5” (standard), 2.75”

Maximum Pressure:..................... 1000 PSI

Output Rate:................................. 9.6 yd3/hr

Maximum Aggregate:................... 1/8” minus

Pump Power:................................ Wisconsin VH4D (30 HP) Gas

Pump Power:................................ Hatz 2M41 (37 HP) Diesel

Pump:........................................... Reciprocating Piston

Grout & Concrete Pumps

Western Equipment Grout & Concrete Pump W30SD

Grout & Concrete Pump W30SD

The Western W30 Super Duty Grout and Concrete Pump was designed tough and held to the highest standards of quality. It comes with all the best features at no extra cost making it the most productive and cost effective pump in it's class.


The W30SD pumps 1/2 inch (-12mm) minus aggregate up to 25 yards per hour and was engineered with the contractor in mind. All it's components are made of the highest quality materials and engineering designed to last while providing you consistent results.


It is equipped with powerful dependable engines (Diesel or Gasoline) and a heavy duty centrifugal clutch. It also uses the hinged manifold locking system, a centralized lubrication system and piston lubrication box which allows smoother pumping, easier clean-up, faster set-up and higher dependability.


SPECIAL FEATURES

• Remote Control with 200 ft of cable


Weight Dry:............................ 2586 lbs Gas

Weight Dry:............................ 2758 lbs Diesel

Length:.................................. 145”

Width:.................................... 60”

Height:................................... 63”

Hopper Height:..................... 50”

Tires:...................................... 14”

Axle:....................................... Single

Hopper Capacity:.................. 6 cu ft

Fuel Tank Capacity:............... 18 gal

Engine:...................................

Engine:................................... Wisconsin VH4D (30 HP) Gas

Engine:................................... Hatz 2M41 (37 HP) Diesel

Cylinder Stroke:..................... 12”

Cylinder Diameter:................ 6”

Outlet Size:............................ 3” HD

Output Rate:.......................... 25 yd3/hr

Maximum Aggregate:............ 1/2” minus

Valve:..................................... Ball & Seat

Pump:.................................... Reciprocating Piston

Plaster Mixers

Western Equipment Manufacturing Mechanical Drive 1200 Plaster Mixer

Mechanical Drive 1200 Plaster Mixer

The Plaster/Mortar Mixer designed exclusively for the professional with a powder coated mixer and a galvanized engine cover for extreme corrosion resistance.


The Mechanical Drive 1200 Mixer is our plaster/mortar mixer designed exclusively for the professional.


Weight Dry:...................... 1220 lbs

Length:............................. 78” -   108” (with tongue)

Width:............................... 57”

Height:.............................. 60” -   77” (with handle)

Hopper Capacity:............. 12 cu ft. or 4 bags

Tires:................................. B78x13

Axle:.................................. Single

Suspension:...................... 7 - Stack Leaf Spring

Drive:................................ Oil Bath Enclosed Transmission

Power Source:.................. Honda 3X390. 13 HP Gas

Power Source:.................. Robin 11.5 HP Gas

Power Source:.................. Kohler 15 HP Gas

Power Source:.................. Hatz 1D41 7.6 HP Diesel

Power Source:.................. Lambardini 10HP Diesel

Power Source:.................. 5 HP 1ø 208/230V Electric

Power Source:.................. 5 HP 3ø 230/460V Electric

Western Equipment Manufacturing Hydraulic Drive 1200 Plaster Mixer

Hydraulic Drive 1200 Plaster Mixer

All the features and quality of our mechanical 1200 Mixer with a heavy duty low maintenance hydraulic system that gets rid of Clutch and Transmission while bringing the reliability and added features of Hydraulics.


KEY FEATURES

• Stronger engine options allows for higher mixing torque

• Reversible drive for safe & quick release of jams

• Pressure release valve to prevent damage in case of jam


Weight Dry:..................... 1220 lbs

Length:............................ 78” -   108” (with tongue)

Width:.............................. 57”

Height:............................. 60” -   77” (with handle)

Hopper Capacity:............ 12 cu ft. or 4 bags

Tires:................................ B78x13

Axle:................................. Single

Suspension:.................... 7 - Stack Leaf Spring

Drive:............................... Oil Bath Enclosed Transmission

Power Source:................. Hatz 1D41 7.6 HP Diesel

Power Source:................. Lambardini 10HP Diesel Pull Start

Power Source:................. Kohler CS Pro 15 HP Gas Pull & Electric Start
